Proaim Kite-22 Starter Package - 24.5ft Camera Jib Crane for Video Film Productions

Proaim Kite-22 Starter Package - 24.5ft Camera Jib Crane for Video Film Productions

150mm Bowl Tripod Stand & D-33 Camera Dolly

€1.948,00 - €1.948,00
€1.948,00
€1.948,00 - €1.948,00
€1.948,00
or Buy now, pay later. Choose Klarna Pay Later / Slice it during checkout.

SKU : KITE-22-STARTER

AT A GLANCE

Payload
20 kg
Jib Length
24.5 ft
Includes
Proaim kite-22 Telescopic Camera Jib Crane
Proaim 150mm bowl Jib Stand
D-33 Pro Camera Dolly
Best For
Film Production
Music Videos
Event Shoots
Cinematic Crane Shots

Secure checkout | Fast delivery | 30-day returns | 1-year warranty

Kite-22Camera crane starter package

24.5 ft of reach. Up to 20 kg.

The Proaim Kite-22 Starter Package pairs a 24.5ft camera jib crane for video film productions with a 150mm bowl tripod stand and D-33 camera dolly, built for film production, music videos, event shoots and cinematic crane shots.

Payload

20kg

45 lb

Max camera package, incl. pan tilt head.

Jib length

24.5ft

7.5 m

Total jib crane length.

Dolly capacity

800kg

1763.7 lb

D-33 Pro floor dolly.

Operator with the Proaim Kite-22 camera jib crane on the stand and dolly

01Ultimate solution for professionals

Crane, stand and dolly in one package.

Proaim unveils the Kite-22 camera jib crane to let you explore your cinematic world, giving you the whole spectrum of creative ideas across different geographic scenarios and in-studio angles.

The well-engineered crane includes a robust tripod stand and a portable floor dolly, delivering a rock-solid foundation for ultra-smooth shots. Its high-grade aluminum construction offers unbeatable strength and holds most camera setups.

24.5 ftJib crane length
20 kgMax camera package
3-in-1Crane, stand & dolly
Kite-22 octagonal telescopic arm sections, with a close-up of the section end

02Seven sections. Five lengths.

Well-designed arm sections.

The modular octagonal arm sections reinforce the sturdiness of the Kite-22 camera jib crane. It is divided into seven sections, each measuring 4′ in length, overlapping by up to 1′ for varied lengths.

Arm length adjusts from 12.8 ft to 24.5 ft (24.5, 22.3, 19, 15.10 and 12.8 ft) to meet any professional demands. Each section is pulled from the previous one, so you can store unused sections in the tail as ballast weight and lighten your counterweight demand.

7Arm sections
4 ftEach section
Octagonal3 mm wall
Kite-22 jib crane on the LW-150 stand and D-33 dolly at an outdoor event

03Solid foundation with mobility

Steady on the stand. Mobile on the dolly.

The Kite-22 Starter package comes with the LW-150 heavy-duty jib stand to provide excellent stability to your heavy camera setups. It combines high-quality materials, technological expertise and superior design to provide the ideal support needed to take the perfect shots. The tripod supports a payload of up to 250 kg / 551 lb and is highly stable in use.

The included D-33 Pro Dolly, a compact and versatile pro video dolly, adds mobility to the crane, and the locks on its wheels ensure static, jerk-free shots and easy assembly.

250 kgStand capacity
150 mmBowl mount
Wheel locksJerk-free shots
Kite-22 crane package in its customized storage cases

04Simplified carrying

Packed, protected, ready to travel.

The complete crane package fits in customized storage cases to ensure full protection, and the cases are easy to carry to different sets and locations.

A ten-pocket tool roll pouch gives rapid access to Allen keys, wrenches and other hand tools, keeping them neatly organized so you can work quickly and efficiently.

ProtectedCustomized storage cases
10-pocketTool roll pouch
51″Jib carrying case

05In-action videos

See the Kite-22 Starter in Action

Proaim Kite-22 camera jib crane

Proaim Kite-22 camera jib crane

Proaim Kite-22 camera jib crane

06Specifications

Telescopic camera jib

Jib Arm MaterialHigh Grade Aluminum HE30
Jib Arm ShapeOctagonal
Height from Ground19ft(5.8 Meter)
Jib Arm Thickness3mm
Jib Crane Length24.5ft (7.5 Meter)
Jib each Arm length4ft
Crane Pan LockNoNote: The knob can temporarily hold the jib in place when perfectly balanced, but it doesn't fully lock; any slight force will allow movement to resume.
Crane Tilt LockNo
FinishBlack Powder Coated
Coupling Jib Arm SectionsA union coupling design of Jib Arm is done by washer and Steel bolt and shank with external clamps as well as Pin Lock for double locking System
Jib Arm Break downs to7 Sections of 4ft each
Camera Platform LevelingBy Control Cable
Stress cableHigh carbon steel with electro galvanized 4mm tested wire at 800kg
Multiple AlignmentMultiple user friendly alignment of Stress Cable is provided For making Jib Stand straight without any curve
Carrying Case size51 inches
Jib Crane Weight30 kg / 66 lb
Max Camera Package Load Capacity (including Pan Tilt Head)20 kg / 45 lb

Jib tripod stand (LW-150)

Weighing Capacity250 kg / 551lb
Material UsedSolid Aluminum
Hub Assembly MaterialHigh Grade Aluminum HE30
Bowl Mount150mm
Bowl Thickness30.8mm
Stand Minimum Height With Bowl2ft 2 inch
Stand Maximum Height With Bowl3ft 2 inch
Distance from Center22 inch
Weight of Stand6.7 kg / 14.7 lb
Weight of Spreader1.8 kg / 3.96 lb
SpreaderMax Opening : 24 inch
Min Opening : 15 inch
Length of Hard Case28.7 inch

Jib arm dimensions

Jib Arm Octagonal TubeOuter DiameterInner Diameter
Ist Section(weight section)164mm156mm
2nd Section154mm146mm
3rd Section144mm136mm
4th Section134mm126mm
5th Section124mm116mm
6th Section114mm106mm
7th Section (Top Section)104mm96mm

D-33 dolly

Material UsedMS powder coated
BoltsSteel bolts with washers
Wheels Diameter148.7mm
Wheels Thickness49.40mm
Wheel MaterialPolyurethane
Central Distance72cm
DimensionsFolded (L x W x H) 84 x 28 x 22 cm
Doorway Width - 144cm
Height From Ground9 inch
Weight of Dolly15.2 kg / 33.5 lb
Dolly TypeThree leg Floor dolly
Wheel LockYes
Maximum Load capacity800 kg / 1763.7 lb

Balancing chart

Jib arm lengthSelf BalancingWhen 2.2lbs weight is on the Head Plate
24.5 ftabout 121.5 lbsaround 133 lbs
22.3 ftabout 119 lbsaround 128 lbs
19 ftabout 116 lbsaround 122 lbs
15.10 ftabout 114 lbsaround 117 lbs
12.8 ftabout 112 lbsaround 115 lbs

Height range

Jib arm height while your stand is adjusted at its maximum height of 4ft

Jib lengthHeight
24.5 ft19 ft high
22.3 ft16.6 ft high
19 ft14.3 ft high
15.10 ft12.2 ft high
12.8 ft10 ft high

Packing info

CaseProduct Volumetric Weight (with packing)Product Gross Weight (with packing)
Case 115 kg / 34 lb22 kg / 49 lb
Case 212 kg / 28 lb17 kg / 37 lb
Case 343 kg / 95 lb30 kg / 69 lb
Case 413 kg / 29 lb14 kg / 31 lb
Case 515 kg / 34 lb17 kg / 39 lb

In the box

  1. 01Proaim kite-22 Telescopic Camera Jib Crane (P-22)
  2. 02Proaim 150mm bowl Jib Stand with spreader (LW-150)
  3. 03D-33 Pro Camera Dolly (D-33)
  4. 04Proaim Customized Storage cases for Camera Jib Arm & Jib Stand & Accessories
  5. 05Tools and Tool Pouch/Wrap
User manualPDF ↓
Fast deliveryOn all orders
Quick supportEfficient customer service
Easy returnsUp to 30 days
1-year warrantyOn all products

Q&A

Ask a Question



  • Hello, I would like to know if this package includes any heads. If that is not the case. What head should I buy?

    In this package, the head is not included.
    SKU of pan-tilt heads that are compatible with this product :
    SKU : PT-JR
    SKU : PT-SR
    SKU : PT-GOLD
    SKU : PT-SPIN-3

  • Does the design help reduce counterweight usage?

    Yes. Unused arm sections can be stored at the rear, helping balance the system and reduce counterweight requirements.

  • Can I move the crane during a shoot?

    Yes. The included floor dolly allows smooth repositioning, while wheel locks keep the crane steady for static shots.

  • Can the jib length be adjusted for different shots?

    Yes. The modular arm design allows quick length changes ranging from 12.8 ft. to 24.5 ft. (24.5ft, 22.3ft, 19ft, 15.10ft & 12.8ft) to meet any professional demands.

  • What comes included in the Starter Package?

    The package includes the Kite-22 jib arm, LW-150 heavy-duty tripod stand, D-33 floor dolly, tool pouch, and protective storage cases.

  • Which size of Tripod legs can fit in the D-33 dolly?

    The tripods with up to 48mm diameter legs can be used with the Proaim D-33 Portable Camera Tripod Dolly.

  • How to assemble Kite-22 crane, i am very confused ?

    "Here is the assembling video of the Kite 22 Crane Jib:
    https://www.dropbox.com/s/ajrtm7ywfsr7f5v/Kite-22-crane-assembly-Final.mp4?dl=0"

  • Hello, is screen includes in the crane packages ?

    The Proaim Camera Crane Packages does not include the monitors or screens.
