Proaim Drive Wireless Follow Focus
WIRELESS FOLLOW FOCUS SYSTEM
Proaim presents its exclusive wireless Follow Focus that allows you to set up a wireless lens control system on your camera equipped with a geared lens and either 15mm or 19mm support rods. It assists the camera operators in adjusting the focus or focal distance (zoom) of the camera shooting remotely. The Wireless Follow Focus can be used along with matching camera control gear like DSLR rigs, sliders, Steadycam kits, cranes/ jibs / dolly, Easy Rigs etc. The high torque motor and a fast reaction speed allows to keep your subject in focus no matter how it moves. The High grade controller features four memory buttons to record different focusing points that can be used repeatedly and also can be randomly switched and combined wilfully.
Now Remotely control your lens's focus with our
Proaim Wireless Follow Focus.
Note: Two styles of infrared transmitter are available, Nikon and Canon.
Kindly leave a note while placing your order.
Video is for demonstration only
Actual Product may vary due to Product Improvements
- Constructed with rugged aluminium extrusion.
- Choice of 7 frequency bands using colour coded TX / RX system.
- New side pointers for operating the focus knob side on.
- 4 Memory presets.
- Cine style focus wheel.
- Powered via single 9V battery for around 10 hours operation.
- Conveniently attaches to operator via integrated belt clip.
- Rugged aluminum enclosure.
UNIQUE MEMORY FUNCTION
The Memory Buttons 1,2,3,4 allows to record the focus on four items manually. In next shooting, you just need to press the memory and it will automatically adjust to the focus you settled last time with manual adjustment again.
FAST WIRELESS TRANSMISSION
In the ground, the remote control features transmission range up to 150m in outdoor open area, without any wall blocking. The device functions on a wireless radio frequency, without the interference of ordinary frequency range and is completely harmless to humans.
- Data light indicates strong connection signal with TX unit.
- Frequency select light indicates a frequency match with TX unit by color.
- Powered via 9 volt chargeable battery and direct through 12 volt adapter.
- 3 pin mini xlr cable connector for motor connection.
- Rugged aluminum enclosure.
Note: Two styles of infrared transmitter are available, i.e. Nikon and Canon. By default, we ship the infrared transmitter for Canon. If you want the transmitter for Nikon, kindly leave a note while placing your order.
Wireless Follow Focus is being used by videomakers worldwide.
Connecting Manual follow focus with cranes, sliders, shoulder rigs & Steadycam leads to shaky results.
Produces Smooth Professional Results when matched with : Crane, Slider,
Shoulder rig & steadycam.
QUICK LOCKING BUTTON
While using follow focus, fix the lower side of locking button onto 15mm rods connected.
Accessories included to use the kit on any set
RECHARGEABLE BATTERY with CHARGER
Precisely designed wireless follow focus for today’s advanced video makers.
The supportive accessories are for Demonstration purpose.
- 2 x Quick lock Buttons
- Servo motor
- 2 x Drive gear
- Follow focus gear ring
- 2 x battery
- Battery charger
- Screw driver
- Hard case
Q: Can I use this follow focus with Cine lenses? Just wondering if the higher torque motor is needed?
Ans : No, this follow focus is not compatible with cine lenses.
Q: Can I use it for zoom control ?
Ans : Yes, this wireless follow focus can be for zoom control.
Q: How long time it takes to charge the battery?
Ans: It will take around 45minutes to 1hour to charge the battery completely.
Q: What is the type of battery used in it?
Ans: This Drive wireless follow focus has 2pc rechargeable battery of 9 volt ( 800 mah) each.
Q: What kind of lenses it can be used with?
Ans: This can be used with all standard lenses with 0.8 gear pitch.
Q: How long is the cable of the controller?
Ans: There is only one cable on receiver side for motor ie. (45 cm).
Q: What is the connector in the controller?
Ans: The connector on receiver chasis is (3 pin mini XLR male) and on motor wire end is (3 pin mini XLR female).
Q: Is it compatible with samyang lens on canon 5D and Sony A7S?
Ans: Yes, it is compatible with samyang lens on canon 5D and sony A7S camera.
Q: Is it returnable for a full refund if it doesn’t meet my expectations upon delivery?
Ans : Yes, absolutely. We always backup our sales. In case, you don't like the product, we take it back within 14 days and you get a 100% refund.
Q: What is the warranty?
Ans: We provide 1 year warranty from the date of purchase. Items which are covered by the warranty period will be replaced at no cost to the customer. Replacement parts of the product will be provided at nominal cost (covering the cost price of the replacement parts only) to the customers after the Warranty Period has expired.
